The CMSSC CM Storm Scout Club ver.2.0

[Enigma8750]

Logo by: K10

Here is our New Patch

http://www.youtube.com/watch?v=vdI-ha34X7w

http://www.youtube.com/watch?v=7aVl7...yer_detailpage

Attention all Scouts.

To Join.. Please fill out this Short form

So that we can have a better count of our Current Members.

Because of The Extreme Popularity to this Thread some of our membership had to be moved to Techreaction.net All other CMSSC Threads are not legit.

The Scout of any fire team is always the most stealthy and the most intelligent of the group. It is his mission to seek out all enemy targets and report their whereabouts back to Command. This Case Delivers the INTEL and AMD that command Needs.

For Special Specific Build or CM Storm Scout Information. Consult our highly trained Staff of Soldiers that are committed to their Specialty
.

Animation By: gtsteviiee

Cooler-Master has deployed the Storm Scout, a True LAN Gaming Chassis. Mobility, Security and 20 years of advanced technology converge in one rugged portable mid-tower chassis. Every Scout is engineered with Storm Tactics: a dedicated focus on Strength, Security and Control. The Scout blends into the darkness with a menacing all black interior showcasing your internal hardware.

An automotive tinted side window with dual fan exhaust brings efficient cooling with subtle transparency. A single button triggers stealth mode deactivating cooling fan LEDs. This covert outlook is complimented by innovative internal designs allowing swapping CPU coolers without motherboard removal. Inside, intelligent cable management maximizes space while supporting internal 2.5" and 1.8" SSD bays. On top, a rugged, steel reinforced handle allows the Scout to be easily wielded in a single hand.
Expansion Slots Standard x 7, Special x 1
Power Supply Standard ATX PS2 (optional)

GPU Specs. 10.5 inches of space from back of case to Drive Bays.

Recent Intel has determined that the 4870,
4870x2,
5770,
5850,
5870,
5890
with a little bending or cutting and the GTX 285

will fit in this case

CPU Cooler Specifications

With 2 Side Panel Fans Installed. 120x120x25
(146 mm.) CPU to Top Side Panel Fan Distance.

With Only the Bottom Side Fan installed
171 mm.

CPU to Side Panel Distance NO Fan installed on the Top of the Side Panel

Heat-sink Dimensions 120 x 120 x 158mm to 169mm is the optimum size range for this case.

Top of the case to the Bottom or Vertical dimensions of the case should not exceed 120mm.
Side to side dimensions 140 mm.

Example of too big is the Cooler Master V10 (L) 236.5 x (W) 129.6 x (H) 161.3 mm
Its not the height or the width of this cooler but it is 10 mm too tall from top to bottom.

Scout Info.
Fan Specs.

Cooler Master High Performance 120MM R4 Series RED LED Case Fan - Brand New $9.99
[R4-L2R-20CR-GP]

Overview
R4 series fans offer a unity of maximum rotational speed and optimum airflow. Using a unique long-life sleeve bearing fan, the R4 series offers long life rating of 50,000 hours. R4 series fans perform at a maximum of 90CFM at 2000RPM. These R4 series are available in red, green, blue LED and dark smoke (no LED).

"Front: 140mm Red LED Fan x 1; 60 CFM; 30,000 hrs life expectancy (included)"
"Rear: 120mm Red LED Fan x 1; 44 CFM; 35,000 hrs life expectancy (included)"

Please remember that Sleeve bearings are only good for the vertical position. They wear prematurely in any other position. That why blowhole or top case fans are usually ball bearing.

Included Accessory 1.8 or 2.5 to 3.5 inch mounting bracket for SSD or HDD
UPC Code 884102004537

The Side vent window of the Storm Scout is such a nice shape and tint is very nice.. Molded in color.

Be advised. Clean this window with a one teaspoon of Dawn dish washing liquid and water mixture in a spray bottle. Any other cleaners like Windex or ammonia type additives can dull the finish of this window.

The Interior of the Storm Scout is impeccably thought out. Nothing was overlooked. There are holes for wires. An opening for the CPU Back Plate and tie down points for wire management. Recent Intel has determined that the 4870x2 and the GTX 285 will fit in this case.

Adding a Hard Drive could not be any easier. The drives face forward for easy install. Just press in the included drive brackets and slide the drive in till it clicks. Its locked in and ready to go in seconds.

Unlike the Antec 900. This case includes a wire management system that is second to none.
Just Look at the Steel Skeleton on this case handle.. This Case is no Plastic Sissy.

Taking Great Pictures of your Scout.

How to Remove your Top Panel Cover.. By GoodInk.
Looking for parts and fans for your CM Storm Scout

If you would like to become a member of the CMSSC please take some time and fill out this short form.

Performance-PCs.Com
FrozenCPU.com
CM Storm Scout Owner's Manual
CM Direct buy parts list.
Cooler Master Storm Scout Parts
Cooler Master Refurb Cases. Great Prices.

Please include some pictures of your rig and comments on what you like about the Cooler Master Storm Scout.

This Thread is dedicated to the memory of
Medal of Honor Winner

Captain Ed Freeman

In memory of Chopper Pilot Capt. Ed Freeman. The Patron Saint of Storm Scout Builders and Soldiers that have little to no hope of Survival.
Semper Fi.. Do or Die.

HassleHoff APPROVED.

[Enigma8750]

Tips and Tricks for your CM Storm Scout from the Scouts themselves.

Cutting Perspex or Plexi-Glass Case Windows.
Cutting Fan holes and mounts in your Plexi or Perspex
NEW SSD SET UP TIPS AND TRICKS.


Building Basics
Wire Management Secrets

So Easy A Caveman Could Do It.

It would be a good Idea to purchase one of these when you are planning your build, Just in Case.
Run your CPU wire under the motherboard before installing the board. It is really a neat trick and makes an Even Neater Build.

http://www.performance-pcs.com/catal...oducts_id=2514
Kev_b says that making a cutout on your top Blow Hole fan, can cut wind resistance and allow the fan to run more efficiently.

A Martini Glass was used as a Template for these holes.

K10:


Remove front panel.
disconnect all wiring that goes to the top panel.
Remove optical drive and anything in the 5.25" bays. Remove two front screws of top panel (in the top corners behind front panel).
Remove the top fan and the remaining two screws in the rear top of the top panel.
Reaching in through the 5.25" bay gently pull some slack in the wiring. This may require some force, just use caution.
When you have enough slack, start to pull up on the top panel.
At first it will seem like it's still connected, but it is not. Firm and gentle force will cause it come away from the case. Snake out the wiring and voila!
You have done it!
See... I knew you could do it!

Warning... The side window is made of perspex or Plexiglas as we call it here in the States. This material will fade or frost over if you use Windex or any other ammonia based Cleaners on it.

Ha Bill Owen just made a nice pop rivet guide, wasn't someone just asking about that?
- Pop Rivet Guide for PC Case Modding

Cable Crimping and Sleeving Solutions
The Place to go for the Best in Sleeving and Cable Management Guru's[/URL]
Best Made Sleeving tool for Cheap!!!

Top Quality Sleeving

Check the difference in Quality.
Clean Cut is on the Left/ PET sleeving is on the right. See the difference.

For the very best in quality Sleeving go with this guy from eBay.[/URL]
For Cleaning Use:
First of all get a empty clean Spray bottle then one teaspoon of Dawn dish washing liquid and fill the rest of the bottle with clean tap water for cleaning. This will clean it so well that it will not attract dust as much. It cleans down to the Bone.




Video Cards
That We Know Fit So Far.
XFX AMD 6870 Black Edition fit just right with room to spare..










Frequently Asked Questions.

TherealFoz Asks?

Enigma8750:
abdidas:

If you plan on hooking up more LEDs to your Control Panel Switch. Use this Wiring diagram.

A perfect wiring job.. use this for reference.

Window Removal:

Tricks and Cool Tips

Baldo 1013 used a part off an old VCR to cover the hard drives.

Seven9st Surfer: Builds a false floor in his Scout.

Seven9st Surfer: Shows how to get those fans connected the right way.

I was wondering about the terminal block mods I had seen before in this thread. After watching tjharlow's videos on youtube, I went out to Home Depot to get supplies, and I finished in like an hour. I've got all 3 fans from the case running off the block, and it works great! It was easier than I though. The rest of the cables are still a mess because I'm waiting till my sleeving gets here, then the whole thing will be done right. [/QUOTE]

Let look at the three different reasons that noise occurs.

1. Vibration from the mechanism.
2. Air flow itself.
3. Vents from the front plastic itself can cause turbulence wind noise.[/QUOTE]

Construction still going .. Please be patient.

[Rockr69]

You FRIKIN ROCK!!!!!!!!!!!

[GoodInk]

Checking in boss.

[Neuromancer]

Nice mods.

Case looks to be exactly like my Rosewill Challenger case I picked up off newegg for $35 shipped a while back. (way too small for my tastes).

Minus the handles on top and side panel window (2x120mm side panel fans instead)


How did the guy with the Corsair TX hide his PSU wires? I tried managing mine by pulling them around to the drive bay and it still looks like crap.

[EnJoY]

Nice cases and mods. Although, not a huge fan of CM cases in general. I miss the old ATC's.

[Blue Destoryer]

Hey boss, just checking in!!

[Enigma8750]

Cool Points "Board of Fame"..
Each "*" Represents One Cool Point

Rockr69 ***** ***** ***** ***** ***** ***** *****

Gen BriSleep ***** ***** ***** ***** *****

GoodInk ***** ***** ***** ***** ***** ***** ***** ***** ****

Cigarbug ***** ***** ***** ***** ***** *****

Rogue1266 ***** ***** ***** ***** ***** *****

BdBanshee ***** ***** ***** ***** ***** ***** ***** *****

Blue Destroyer *****

McDoggie *****

Kev_b ***** ***** ***** ***** ***** *****

Striker36 ***** ***** ***** ***** **

Cyborg ***

Nyarlathotep_75 ***** ***** *****

Kaneda13 ***** ***** ***** ***** ***** ***** ***

B Negitive ***** ***** *****

LostKauz ***** ***** *****

NitroNarcosis ***** ***** ***** **** **

H969 ***** ***** ***** *

Xyrate ***** ***** ***** ***** ***** ***** *****

Burned *

pengu56 ****

gwpjr ***** **

Cerbus2 ***** ***** ***** *****

metawin ***** *****

wez ***** ***** ***** ***** ***** ****

[Enigma8750]

The Cases of the CM Storm Scout Club Members

This one is from me Enigma8750
I call it called Enigma0011, The Cold War Project
She won 3rd. place twice on OCN Mod of the Month and then 5th place Mid tower World Wide from CM Modding Contest. I built it as a show Winner after I saw what Bill Owen had done to the case and I had to try out the Camo Theme mod myself. But from my time. It now belongs to my wife and I as a low wattage alternative to my Big Enigma 0002 Sig Rig and Serves as my Test Machine for Future Builds and repairs.

Kev_B Modded this beauty after the CM690 NVidia edition

This one is the called nVidia Build and it's stunning.

This is dkev's Baby

This one is Trecherous Intellect's Build. He's from Los Angeles, California.
He includes a picture of himself and his SIGNIFICANT Memory. Wow!!! What a way to disguise the wires.

This is Pandemahaos's new B'day Build.

This is imh073p's rig. She is hot. Her name is Nitro Scout

bdBanshee's build.

Kracky Calls this The Roost

Here is Xilii

Maxilla's Case

Behemoth777's Case is called Shadow and Flame and its a really nice Build.

Rom3000's Case

This is Photonmoo's Machine

This is BriSleep's Build ATI 5870 Dark and Blue

HubWub's Mangoes Scout

Lee79's Build is Red Scout

Xiliii's Rig is Red vs. Blue. My favorite web cartoon.

Tigs. Unfinished build. He calls it First Build

This is Patricck's Rig

This Is KritonX Monster Rig

This Is Rouge1266's Rig

This Is Stvptrsn's Rig

MlbrottarN's RIG

Jayte's Build

GAMERIG: UnderWater Blue

rfJunkie: Prototype Test Unit

FerosiousWill's nice H-50 Cooled Rig

XX-Sunny-XX Video

Rockr69 Vista-Rocker is Old school P4 AGP 3850
FerociousWills Build: 09 Scout
QuantumReality: AMD Flagship
coreyL: p55 System

985323's New System

michaeljr1186: Fraternal Twins

Very Nice Vanilla Case. Only One CC on the Floor

AmBiGuOuS Rig

[Enigma8750]

More Cases from our Members

gwpjr: Glock Shock

Game oveR

Sect9

DKev's shots



imho73p's EVGA Shot



Photo by ambiguous
Photonmoo's Glowing Liquid Cooling Collage


Here Comes the ROOSTER!!!

grasshopper1g's Rig Video
YouTube- Phenom ll x3 720 ati 5770 crossfire[/url]

BriSleep's i7 5870

Dkev's Fan Stack

Xquisit. Thats all. XXXquisit

[B]
Flipd's Xynapse Rig.. That is a 5870 in there.

Pictures by AyeYo


Seven9st Surfer's Play STATION

Rockr69's Build

This picture looks like an industral Furnace.. Awesome Build Rocker.
[IMG][/IMG]
MaxBlast_NL's Build


baldo_1013's Clean Build with Cool hard drive cover


The ronin's Eagle One

linkin93's Sharp rig.

ROM3000.. Lights in the Key of Green.

imh073p's : DeathStar

AmBiGuOuSz: My System


Baldo 1013 : AmKulet

And then Baldo 1013 Takes it another step....

Diabolical999 with his Hominis Nocturna


GTR Mclaren and His System

Shiggins Virtual CM Storm Scout


Gen Brisleep's Wife's Rig


GoodInk's Awesome Wicked Build

Mr-Charles with his Scout Seal Edition

[Enigma8750]

More Pictures of our Members
Builds
McDogi's Red and Black Scout.

Kev B's new Scout.

Frag Mortuus's Build

Striker-Reactor Build. Mod of the Month Winner

murcielago585 with his 570 Econo Build.. IT fits.

Hards 80- Lucky #1

Shadow of Intent-Magma- Showing the 6870 fits.

linkin93- A Console's Nightmare. GTX 460 installed.

Simford's-Dangerous Scout- Feline Edition..

Telnets Amazing Case How Sweet that Build. That awed a modder like me.....

[Enigma8750]

ROSTER of MEMBERS

General Enigma8750
Maj General Rockr69
Maj General Brisleep
Brig Gen GoodInk
Brig Gen Cigarbug
Brig Gen. Rogue1266
Colonel Nyarlathotep_75
Colonel Destroyer
Lt. Colonel B NEGATIVE

[Enigma8750]

Nice cases and mods. Although, not a huge fan of CM cases in general. I miss the old ATC's.

Actually I miss the old Stackers. Those were some fine cases..

Kinda looks like my Stacker.

[Enigma8750]

SEMPER FI...DO OR DIE..

That is our Mantra that is our Call
those who never let another Member Fall
Or never leave a man down.

[The Duke]

I am so confused ... cool mods though

your quoting of your first post needs some reworking though
