THE COOLER MASTER STORM TROOPER CLUB

[Enigma8750]

Good Luck Finding one.. $189.00 US MSRP.

http://www.youtube.com/watch?v=dzRCq6mZwTM

The Exterior is painted Black and the front shows a total of 9 Drive Bays included in the case. The Front also includes an X-Dock which can be used to Plug-in a SSD Drive, The top design comes with a handle and the front connector panel which includes Power On/Off, LED On/Off, 2 x USB 2.0, 2 x USB 3.0, E-Sata, Audio Microphone Jacks and HDD/CPU Usage LED’s. There are also 3 Holes at the back to allow for watercooling setups. A meshed side panel is included on the case which may allow room for 2 120mm fans but this is yet no known.

Storm Trooper Features

• Damage resistant rubberized outer surfaces with a built-in digital fan controller

• Supports high-end hardware such as XL-ATX motherboards, multiple GPUs in SLI or Crossfire

• Room for future upgrades with support for up to 14 HDD or SSD

• Dust filters on every intake that are removable to allow easy cleaning

• Support for several 240mm radiators

• 6 fan speed settings and fan LED control via fan controller

• Front I/O panel with 2 internal USB 3.0 connectors

• Easy transport with handles and a hidden tool box for carrying accessories

• Easy cable management and routing

• Two 90 degree removable and rotatable HDD cages each with an attached 120mm red LED fan

SGC-5000-KKN1 Specifications

Material Case body........ Steel; Front bezel: Mesh and plastic

Expansion Slots.. 9 + 1

Dimensions...... 250 x 605.6 x 578.5mm / 9.8 x 23.8 x 22.8"

Net weight....... 13.7kg / 30.2 lbs

MB Type....... Micro ATX / ATX / XL-ATX

5.25" Drive Bay..... 9

3.5" Drive Bay........ 8 (converted from 5.25" bay by two 4-in-3 HDD cages)

2.5" Drive Bay.... 13 (8 converted from 5.25" bay by two 4-in-3 HDD cages)

Front I/O USB
USB 3.0 x2
USB 2.0 x2
e-SATA x1
Audio in/out

Cooling System
120mm x2 front
200mm top
140mm rear
120mm x2 side (optional)
120mm x2 bottom (optional)

Max. Graphics Card Length.......... 322mm / 12.7"

Max. CPU Cooler Height........ 186mm / 7.3"

Benchmark Reviews Says.

The sturdy, rubber-padded handle dominates the top of the Storm Trooper. Behind the handle is a meshed area covering the top of the case and providing exhaust airflow for the included 200mm top fan. The fan can be removed and replaced with a 2x120mm radiator. The front and top of the case are covered in a soft-touch, rubber-like material.

Benchmark Reviews also reports.

A giant illuminated power button with the Storm logo dominates the I/O panel at the top front of the case; below it are buttons for the built-in fan controller, which can control the lights of three fans and the speed of four fans. By pressing the "-" and "+" buttons, you can choose between six different fan speeds, with LEDs above the switches visually indicating the chosen speed. There are also power and hard drive activity LEDs, microphone and headphone jacks, a reset button and ESATA port, and four widely-spaced USB ports. The wide spacing of the USB ports will minimize the chance of "fat" USB devices interfering with adjacent ports. There is no FireWire (IEEE 1394) port, but this is falling out of use anyway and most users won't miss it. The two SuperSpeed USB 3.0 ports are connected to a cable terminating in a USB 3.0 header, which is only useful if you have a recent motherboard that has one of these headers. Surprisingly, Cooler Master does not provide a USB 3.0->USB 2.0 adapter cable, so if your motherboard doesn't have a USB 3.0 header, you won't be able to use these ports.

One odd thing is that Cooler Master doesn't supply a power light header for your motherboard's front panel connector; instead, the power LED gets its electricity from the same 4 pin Molex connector the fan controller does. While this works, it means you don't get a blinking power light when you put your computer to sleep.

http://www.youtube.com/watch?v=XHbrs...&feature=feedu

The Cooler Master Storm Trooper Club

is dedicated to the honorable

Seal Team VI

RIP "08-06-2011"


This case was also introduced on the 20th Anniversary of Nevermind Album from Nirvana.. Curt.. RIP.. We loved you and you didn't feel that you deserved it. But who does?

http://www.youtube.com/watch?v=PbgKE...feature=relmfu

[Enigma8750]

How to Join.. Wait for the 26th of SEPTEMBER 2011
POST A PICTURE OF YOUR STORM TROOPER AND FILL OUT THE FORM FOR MEMBERSHIP AND YOU ARE DONE.
STAY HONORABLE AND STRONG.

MESS WITH THE BEST, DIE LIKE THE REST.

Founder... Unimatrixzero with Father Enigma8750
Co-Founder .... Rogue1266

[Enigma8750]

Technical Post...

http://www.youtube.com/watch?v=1ak29...eature=related

SGC-5000-KKN1 Specifications:


Material Case body: Steel
Front bezel: Mesh and Plastic
Expansion Slots: 9 + 1
Dimensions: 250 x 605.6 x 578.5mm / 9.8 x 23.8 x 22.8"
Net Weight: ...... 13.7kg / 30.2 lbs
MB Type: ..... Micro ATX / ATX / XL-ATX
5.25" Drive Bay: ...... 9
3.5" Drive Bay: ....... 8 x two CM STACKER STYLE 4-in-3 HDD cages)
2.5" Drive Bay: ....... 13 spaces
(8 converted from 5.25" bay by two 4-in-3 HDD cages)
Front I/O USB 3.0: ...... 2 each,
USB 2.0: ..... 2 each
e-SATA: ....... 1 each
Audio In/Out: ..... Standard mini banana Jacks recepticals



Cooling System:

Front: ........ 2 x - 120 x 120 mm
Top Fan: ..... 1 x ..... 200 X 180 mm
Rear Exhaust fan: ..... 1 x - 140 x 140 mm
Side Panel Fans (optional): .... 2 x - 120 x 120 mm
Bottom (optional): .... 2 x - 120 mm
Max. Graphics Card Length: ....... 322 mm / 12.7 inches
Max. CPU Cooler Height: ............ 186 mm / 7.3 inches

Mobo connections & Case connectors

[Enigma8750]

SAVE MORE

[Enigma8750]

SAVED AGAIN 2

[Neuromancer]

MMM red heads

the front has that classic cooler master style with the whole front being 5.25" bay covers. Are they all actually usuable? Was kind of hard to tell from the review.

If so thats going to open up some more options for vaser coolers

[Enigma8750]

Vaser Cooling? Looks like another Google Search for me .. I am only speculating because the only friend I have that knows the ins and outs of this case has signed a non disclosure contract. I would say that the front end is much like the cosmos where all the bays are usable but there will probably be block units that fit inside for SSD HDD use at the bottom. but the fans there and the ability to put drives on the floor of the unit really opens up some really cool possibilities for Water Cooling from the side. and out the front. that would be a really cool thing.

[Neuromancer]

LOL I meant Wasser not Vaser. Thats what I get for trying to Duetsch phonetically.

(I just finished watching that german youtube vid you posted and was referring to water cooling )

[Enigma8750]

Oh ya vol. Wasser coolink is goot. ya..

[Archer]

Oh ya vol. Wasser coolink is goot. ya..

Nein, es macht die kaput, wenn das Wasser austritt

Try to say this three times fast: panzerkampfwagon

EDIT: this is the CM: gepanzerten PC-Gehäuse

[Enigma8750]

Cooler Master is definitely going to sell the case first in Europe obviously.

More leaked Trooper Pictures

I Can't wait to Mod this New Case.. Coming soon to a pair of Eyes near you !!!

[Rogue1266]

I can't wait until it comes out.... I really need to physically look at this case....

[Enigma8750]

I can't wait until it comes out.... I really need to physically look at this case....

Well I will be doing a mod and info thread here as soon as it is available to the general public. I know someone that might have one now but he signed a secrecy oath and he is an honorable man but I can't wait to see what he does with it. If in fact my speculations are correct. I guess all that hitching to them for an updated case came through.

[DireLeon2010]

I can't wait until it comes out.... I really need to physically look at this case....

Copy that. I hope they get it at Fry's on release date, then I can get a good look maybe even pick it up/look inside and out and decide if I want to upgrade or not. (horrible sentence)

Any word on the handle? Hope it's as sturdy as the Scout.

[Enigma8750]

I doubt that they would have made the the scout with a bicycle like reinforcement without offering the same on their newest Top Dog. I think that is going to be a very servicable handle IMHO.
